Soundproofing Deadening Ratings: STC, OITC, and Damping Specs

The Physics of Soundproofing vs. Sound Deadening

In acoustic engineering, 'soundproofing' and 'sound deadening' are frequently conflated by consumers, but they describe fundamentally different physical mechanisms. Soundproofing refers to sound isolation—blocking airborne noise transmission through mass, decoupling, and airtight sealing. Sound deadening refers to damping—dissipating vibrational energy within a structure to reduce resonance, structure-borne noise, and the amplitude of bending waves. Selecting the correct acoustic assembly requires parsing the specific performance ratings that govern these two distinct phenomena.

When an acoustic wave strikes a partition, three things occur: reflection, absorption, and transmission. Mass and decoupling address transmission (soundproofing). Damping addresses the partition's internal resonance (deadening). A wall assembly lacking adequate deadening will suffer from the 'coincidence effect,' where specific mid-to-high frequencies cause the drywall to vibrate in phase with the sound wave, creating a severe dip in transmission loss regardless of the wall's total mass.

Decoding Airborne Transmission Ratings: STC vs. OITC

The Sound Transmission Class (STC) is the most ubiquitous metric in North American construction, governed by ASTM E90 (laboratory measurement) and ASTM E413 (classification). However, STC has a critical blind spot: it only evaluates frequencies between 125 Hz and 4,000 Hz. It completely ignores low-frequency noise (below 125 Hz), which is where modern mechanical systems, home theater subwoofers, and urban traffic operate.

To address this, the Outdoor-Indoor Transmission Class (OITC) was developed under ASTM E1332. OITC evaluates frequencies from 80 Hz to 4,000 Hz and applies a weighting curve that penalizes low-frequency transmission more heavily. For interior partitions separating living spaces from mechanical rooms or home theaters, OITC is a vastly superior specification metric than STC. According to testing data from Riverbank Acoustics, a partition can achieve a high STC rating while performing poorly on OITC if it lacks the mass or damping required to control 80 Hz to 125 Hz waves.

Structure-Borne Noise and Damping Loss Factors

Sound deadening materials do not block sound; they convert mechanical shear energy into negligible amounts of thermal energy. This is quantified by the Damping Loss Factor (DLF). The most effective architectural deadening strategy is Constrained Layer Damping (CLD). In a CLD system, a viscoelastic polymer (such as Tremco CPG's Green Glue Noiseproofing Compound) is sandwiched between two rigid constraint layers, typically 5/8-inch gypsum board.

As sound waves induce bending in the outer drywall layer, the viscoelastic core is subjected to shear stress. The internal friction of the polymer dissipates the vibrational energy. According to the Green Glue technical data sheets, proper application requires exactly two tubes of compound per 4x8-foot sheet (covering approximately 60 square feet per 5-gallon pail). Applying too little compound starves the shear layer; applying too much creates a hydrostatic lock that prevents the layers from flexing, effectively turning the two sheets of drywall into a single, thicker, undamped sheet.

Mass Law vs. The Coincidence Dip

Mass Law: In acoustics, the Mass Law dictates that for every doubling of a partition's surface mass, the transmission loss increases by approximately 6 dB. However, Mass Law assumes an infinitely large, perfectly limp, and undamped barrier. Real-world rigid building materials experience a 'coincidence dip'—a frequency range where the speed of bending waves in the material matches the speed of airborne sound, causing a sharp drop in isolation performance.

This is where sound deadening specifications become critical. A single layer of 5/8-inch drywall experiences its coincidence dip around 2,500 Hz to 3,000 Hz, which falls directly in the range of human speech consonants and glass clinking. By introducing a high-DLF viscoelastic compound between two layers of drywall, the resonance peak is flattened, effectively pulling the transmission loss curve back up toward the theoretical Mass Law limit. The Gypsum Association's GA-600 Manual provides extensive tested assemblies demonstrating how constrained layer damping recovers the 5-10 dB loss typically seen at the coincidence frequency.

Impact Insulation Class (IIC) for Floor Assemblies

While STC and OITC measure airborne noise, floor/ceiling assemblies must also be rated for impact noise (footsteps, dropped objects). The Impact Insulation Class (IIC) is measured via ASTM E492 using a standardized tapping machine. However, IIC measures the entire floor-ceiling assembly, making it difficult to isolate the performance of a specific underlayment product.

To solve this, the industry adopted Delta IIC (ΔIIC), standardized under ASTM E2179. Delta IIC measures the specific acoustic improvement provided by a floor underlayment alone, tested over a standard 6-inch concrete slab. When specifying sound deadening for multi-family residential floors, rely on Delta IIC, not the total assembly IIC.

• 1/4-inch Cork Underlayment: Yields a ΔIIC of approximately 12-14. Excellent for high-frequency impact (clicking heels), but poor for low-frequency thuds due to high dynamic stiffness.
• 3/8-inch Recycled Rubber Crumb: Yields a ΔIIC of approximately 17-20. Superior deadening for heavy impacts and low-frequency structure-borne vibration.
• 5mm Acoustic Mat (Entangled Monofilament Polypropylene): Yields a ΔIIC of 15-18. Highly resistant to compression set over time, maintaining its deadening properties under heavy static loads like kitchen islands.

Specification Matrix: Matching Material to the Noise Profile

Selecting the correct soundproofing and deadening materials requires matching the acoustic threat to the physical mechanism of the material. Use the following decision framework when drafting specifications:

Scenario A: Home Theater / Mechanical Room (Low-Frequency Dominant)

The Threat: 20 Hz to 80 Hz sub-bass and HVAC rumble. Wavelengths are 14 to 56 feet long, easily bypassing standard mass.

The Specification: Mass and damping are insufficient alone. You must specify a fully decoupled room-within-a-room or heavy isolation clips (e.g., Kinetics IsoMax) spaced at 24 inches on-center to drop the wall's resonant frequency below 16 Hz. Combine this with double 5/8-inch drywall and a viscoelastic damping compound to control the mid-bass coincidence dip. Specify OITC, not STC, for the performance requirement.

Scenario B: Multi-Family Demising Walls (Mid/High-Frequency Dominant)

The Threat: 250 Hz to 4,000 Hz speech, television, and general living noise.

The Specification: Standard STC improvements apply. A staggered-stud or double-stud wall with R-15 mineral wool (which offers higher flow resistivity and better high-frequency absorption than fiberglass) and a single layer of 5/8-inch drywall on each side will achieve STC 55+. Adding Mass Loaded Vinyl (1 lb/sq ft) is highly effective here, as MLV excels at blocking mid-to-high frequencies without requiring the shear constraints of CLD compounds.

Scenario C: Hardwood Floor Over Wood Joists (Impact Dominant)

The Threat: Footsteps and structural vibration transmitting through the floor decking.

The Specification: Specify a high-Delta IIC underlayment (minimum ΔIIC 18) combined with a decoupled ceiling below. The ceiling below must utilize resilient isolation clips and hat channels, finished with two layers of 5/8-inch drywall featuring a constrained layer damping compound. Do not rely solely on the floor underlayment; wood joists will transmit low-frequency impact noise through the structural framing regardless of the floor topping.
